Features

1. The number of tension modules: when the defense zone 1, double defense zone 2;

2. Alarm function: rope tension alarm, wire rope slack alarm, wire rope shear alarm, tension host tamper alarm, self-test fault alarm, power failure alarm;

3. Scope of application: After the installation of four-wire tension fence, the stigma and iron fence of part of the wall have a small range drop. When the distance between the bottom four wires of the four-wire tension type electronic fence and the iron fence is more than 150mm, four or more tensions shall be installed. The fence compensates for the following structures;

4. it can be cascaded with the above four-wire tension host in a single zone;

5. Material: Tension machine body made of aluminum material + anti-oxidation treatment, all accessories screw SUS304 stainless steel;

How it works

A screen of metal wires is deployed around the installation's perimeter, connected to exclusive sensor posts equipped with Strain Gauge Sensors. The resistance of the strain gauge changes relative to the distortion of the sensor caused by load changes and the signal processing unit analyzes the signal including its velocity and using imbedded algorithms decides if the signal is an alarm. The Taut Wire System uses advanced technology which allows it to face all weather conditions, for the sake of intrusion detection only

Technical Parameters
